CT-6-20
Current transformer for operating and residual current suitable for measuring instrument UMG 20CM on DIN rail CT-6-20 - 1401630 6 measuring channels, parallel collection and processing of measured values, class 1, rated voltage max. 720 v AC
Order number: 1401630
EAN: 4251861102334
Monitor, assess and treat
- Current transformer for operating and residual current suitable for the measurement device UMG 20CM
- Residual current acquisition with integrated current transformers (residual currents per IEC 60755 type A)
- 6 measurement channels, individually adjustable for operating current or residual current
- Compact construction, DIN rail mounting
- Parallel acquisition and processing of measured values
- Use in distribution outputs for consumers and systems
| Accuracy class | 1 |
|---|---|
| Gear ratio | 700/1 |
| Width [mm] | 174 |
| Height [mm] | 45 |
| Depth [mm] | 56 |
| Weight in [g] | 300 |
| Mounting type | For DIN rail |
